The number of lanes are indicated by the suffix of the PCIe protocol (×1, ×4, ×8, ×16, ×32).
/pci-express-pcie-2625962-79f643e7768d4b8e81e2eee6cf5b02e7.png)
Pci express x4. No matter what size the PCIe slot or card is, the key notch, that little space in the card or slot, is always at Pin 11. Up to 5000 MBps. 1500G / 0.5 ms.
35 36 Standard cables and connectors have been defined for x1, x4, x8, and x16 link widths, with a transfer rate of 250 MB/s per lane. Up to 4400 MBps. High-end network cards and enthusiast equipment like adapters and RAID controllers use a mix of x4 and x8 formats.
Silicon Power US70 M.2 2280 1TB PCI-Express 4.0 x4, NVMe 1.3 3D NAND Internal Solid State Drive (SSD) SP01KGBP44US7005. There are a small amount of PCI-E mounted solid state drives that prefer an x4 port, but those seem to have been swiftly overtaken by the new M.2 standard, which can also use the PCI-E bus. Each lane is capable of speeds from 250-1969 MB/s, depending on the version of the PCIe protocol (v1.x, v2.x, v3.0, v4.0).
In other words, it's the length of Pin 11 that keeps getting longer as you move from PCIe x1 to PCIe x16. PCIe cards can always operate in PCIe slots with the same or more lanes than the card. X1, X4, X8, X16 16 PCI Express lanes is the default connection width for graphics on most motherboards.
For example, an x8 card can operate in a slot with x8, x16, or x32 lanes.
